The Insulated Suspension Chain (ISC) offers a straightforward solution for rapidly and simply increasing the operating voltage of power lines. Typically, voltage increases can result in lengthy planning approval processes and significant investment costs if the towers need to be modified. However, with the ISC (German: iTAK – isolierte Tragabspannkette), the existing towers and suspension points can remain unchanged, allowing the continued use of the current infrastructure (poles). Additionally, the ISC provides an excellent solution to meet bird protection requirements.

---



Applications

• Overhead lines that are to be upgraded to a higher voltage level



Product

• One Y suspension chain with three insulators arranged in a Y shape (available in porcelain or silicone)
• Insulated conductor loop
• Matching protective fittings



Advantages

• Cost-effective
• Environmentally friendly
• Durable
• Easy to fit
• Tested connection
• Bird protection

Testing

• Type testing in accordance with IEC 60071
• Lightning impulse withstand voltage of 550 kV (positive/negative)
• Power-frequency withstand voltage test: 230 kV (dry/wet)
• Switching impulse withstand voltage test: 742 kV
• Bird protection test
